Rigol Mho934 Mixed Signal Oscilloscope, 4 Channel, 350Mhz, 4Gs/S, 100Mpts, 12 Bit, Mho900 Series

Description

MHO900 Series Digital Oscilloscopes, 12 Bit High Resolution for High Speed, High Accuracy Applications

Product Features

• 12-bit resolution

• Max. 800 MHz analog bandwidth, 4 analog channels

• 16 digital channels, 200 MHz PLA2216 logic analyzer probe (optional)

• Real-Time sample rate: up to 4 GSa/s

• Max. memory depth of 500 Mpts (option)

• Vertical sensitivity 200 µV/div to 10 V/div

• Max. waveform capture rate: 1,000,000 wfms/s

• Digital phosphor display with real-time 256-level intensity grading

• Optional 2-channel, 50 MHz/100 MHz Function/Arbitrary Waveform Generator (Bode plot supported)

• Supports histogram, digital signal analysis, etc.

• Supports waveform search and navigation functions, capable of debugging the signal anomalies faster

• 7” (1024×600) HD touch screen

• Flex knob brings user-friendly experience

• Standard USB2.0 Device & Host, LAN (100M) and HDMI interfaces

• Novel and delicate industrial design, easy to operate

• Supports online upgrade of software version

The MHO900 series is RIGOL’s newly launched economical oscilloscope. Compact in size, it features 1,000,000 wfms/s capture rate, max. memory depth of 500 Mpts (optional), 12-bit high resolution and low noise.

The product supports 16 digital channels. One instrument can make an analysis on both the analog and digital signals to meet the embedded design and test scenarios. With an affordable price equivalent to purchasing an entry-level instrument, you can access the auto serial and parallel bus analysis, bode plot analysis, and other functions to meet the test demands in the R&D, education, and science research fields.

High Performance Rebuilds the Entry-Level Standard

• 800 MHz BW & 4 GSa/s sample rate enable you to address the high-speed signal acquisition challenge.

• 12-bit high-precision ADC, 4096 vertical digitalizing levels, not missing any weak signals.

• Max. 500 Mpts memory depth enables you to record high-speed and complex events, giving you full insight into the full details of high-speed signals.

• Various protocol decodings.

N-in-one Integrated Efficient Test Tool

• Standard 16 digital channels allows you to capture and analyze the digital signals with the analog signals.

• Optional 2-channel, 100 MHz AFG option can output up to 100 MHz pure sine wave, with Bode plot supported for signal analysis.

In The Box

• Power Adapter Conforming to the Standard of the Destination Country

• Ground Cable

• USB Cable

• PVP2350 – Qty 4 Passive Probes (350 MHz) (Standard Configuration for MHO934)
